WSJT-X WILL see the band change, but you'll notice the frequency window turns RED in WSJT-X. If you change your band on the rig, MLDX will see it and pass it down. Change your band in WSJT-X and it will send the change through JT-Bridge to MLDX and your rig will change. Now that the above is done, freq changes on your rig will be caught by MLDX, passed through JT-Bridge, and into WSJT-X. None will work, but Fake it does as well. For PTT method choose CAT, and for Split choose what works. Now under CAT control you should see a box that says Network Server. If MLDX is controlling your rig the "Rig" section here should be "None".ĭrop down the Rig and choose "DX Lab Suite Commander". Open WSJT-X and go into Preferences.Radio. You should now see WSJT-X: 0 on the bottom left, and CAT connections: 0 on the bottom right.
The bottom right of the JT-Bridge window now likely says CAT Address already in use, ignore that I think it's a bug (I've reported it). Put that in there and then tab into another field. Type in a port, can be any, but I used 7374. Look at the bottom of that window, it's a section that says CAT, and the Listen on port is probably blank. Go into the Preferences for JT-Bridge and go to the Network tab. Now, the bottom left should say WSJT-X Connection: 0, that's good. Do that by selecting File.Open and choosing your MLDX SQL file. If it doesn't then you haven't connected it to the log yet. Make sure the top title bar says "Connected to MacLoggerDX". Make sure UDP broadcasts is checked under the Station tab in MLDX.
I probably will do a Youtube Video on it as well, because it's kind of hidden.įirst off, make sure MLDX is controlling the rig, have everything else closed (no JT-Bridge or WSJT-X open). It's possible though, because I finally figured it out. The docs hinted at it, but boy was it a convoluted thing to figure out. All the documentation seemed to state that it was possible to let MLDX control the rig, JT-Bridge be the intermediary, and WSJT-X to see the changes and PTT. So I stumbled across this post because I too was trying to make this work.
